Bioaxenic-G Capsule Filters
Bioaxenic®-G series capsule filters are composed of polypro-pylene membrane. The product shows excellent chemical compatibility, high throughput, low pressure drop characteris-tics, which have a wide range of applications such ...
Bioaxenic®-G series capsule filters are composed of polypro-pylene membrane. The product shows excellent chemical compatibility, high throughput, low pressure drop characteris-tics, which have a wide range of applications such as pre-fil-tration of vaccine production and pharmaceutical water, blood and plasma component separation etc.
| Dimension | |
| Outer Diameter | 87mm |
| Length / Filtration area | 2"(65mm) / 0.12m² 4"(103mm) / 0.22m² 5"(118mm) / 0.26m² 10"(266mm) / 0.65m² |
| Material of Constructions | |
| Media | PP |
| Support | PP |
| Cage/Core/End cap | PP |
| Seal Material Options | Silicone |
| Use Condition | |
| Max. Operating DP | 5Bar(73psi) @ 20℃(68℉) |
